RF Shield Box

This box has two plastic parts Lid and Base (bottom shell) which are assembled together by a stainless steel pin/hinge.
One mold for the lid, the other for the base part. 6 pcs of 6-32 brass nuts insert molded in the lid, 18 pcs of 6-32 nuts and 2 pcs 8-32 nuts in the base.
7 steps silk screen for the lid, RF shield coating inside, and the silicone gasket assembled to be water-tight.
The lid has 5 versions which in one mold with the interchangeable inserts to save the costs.

350-ton injection machine for molding, and then printing, coating and assembly for delivery.
Project No.:
Year:
Material:
Availability:

Previous:
Next:
